CAT 5e outdoor network cable, F/UTP, black
CCA copper mixture for SOHO application, AWG 26/7 (stranded), PE
CAT 5e outdoor network cable, F/UTP, black
CCA copper mixture for SOHO application, AWG 26/7 (stranded), PE
Article details
- non-terminated flexible data-/patch cable for Home-/outdoor usage
- UV and water resistent
- shielded twisted-pair LAN cable
- outer shield: foil screening
- This product is not approved for permanent installation in buildings.
- Meets requirements for SOHO applications (Small Office, Home Office) up to a max. transmission length of 40 m!
Technical specifications
General
Packaging type
Cable Reel
Consumption Unit
1 pc. cable reel
Color
black
Markings
CE, SOHO, SOHO_40
Operating temperature from
-20 °C
Operating temperature up to
75 °C
Cable
Shielding class
F/UTP
Specification
CAT 5e
Cable type
round cable
Cable length
100 m
Inner conductor material
CCA (copper-clad aluminium)
Material cable sheath
PE
AWG
26/7 (stranded)
Number of shieldings
1 x
Meter scaling
yes
Type 1, shielding
foil (aluminium)
Cable sheath diameter (approx.)
5.6 mm
Signal transmission
max. bandwidth
100 MHz
Impedance
100 Ω
Downloads
Packing units:
1 / 4
Item: 57295
EAN: 4040849572951
