Casual
High Speed HDMI™ flat cable with Ethernet
high-speed flat cable for Ultra HD
Casual
High Speed HDMI™ flat cable with Ethernet
high-speed flat cable for Ultra HD
Article details
Let your cable system disappear almost completely and enjoy movies and games with high clarity, high resolution and dazzling quality, even in 3D. What does this cable do to an audio video signal? Nothing. It is, however, precisely this feature which proves its quality. Thanks to pure materials, precise processing, and modern technology, it combines your TV with other devices and the Internet. Just as befits a sophisticated system! Therefore, you can be sure that you get the experience exactly as it was meant to be.
- pure copper conductor and 2-way shielding for clear signal quality
- High-speed HDMI™ for 3D and Ultra HD up to 4K @ 50/60 Hz (2160 p)
- integrated Ethernet channel saves additional network or audio cables
- 24 carat gold-plated contacts for minimum transmission resistance
Technical specifications
General
Packaging type
Retail Box
Consumption Unit
1 pc. in cardboard box
Operating temperature from
-10 °C
Operating temperature up to
80 °C
Warranty
10 years
Connections
Connection, shielding
yes
Connection, length
42.1 mm
Connection, width
20.9 mm
Connection, type
HDMI™ male (type A)
Connection, height
10.8 mm
Connection 2, type
HDMI™ male (type A)
Connection 2, length
42.1 mm
Connection 2, width
20.9 mm
Connection 2, height
10.8 mm
Connection, housing material
PVC
Connection, contact material
gold (24 kt)
Cable
Cable type
flat cable
Cable length
1 m
Inner conductor material
OFC (99,9% oxygen-free copper)
AWG
30
Number of shieldings
2 x
Type 2, shielding
braid (copper) 40x
Inner Conductor number
7 pieces
inner conductor, core diameter
10
Kink protection
both sides
Ferrite core
no
Signal transmission
max. transmission rate
10.2 Gbit/s
Signal amplification
no
Capacity
89 pF
Impedance
100 Ω
Item: 70312
EAN: 4040849703126
