OLED
TV wall mount OLED FULLMOTION (L)
especially for OLED TVs from 37" to 70" (94-178 cm), fully movable (swivel and tilt) up to 30kg
OLED
TV wall mount OLED FULLMOTION (L)
especially for OLED TVs from 37" to 70" (94-178 cm), fully movable (swivel and tilt) up to 30kg
Article details
The OLED Full Motion mount for 37 to 70 inches (94-178 cm) TVs up to 30 kg. Compared to conventional TVs offer OLED TV wider viewing angles, vivid colors, thinner profile and a much lighter weight. Due to the special design of the TVs, the OLED wall mount provides optimal mounting solution. The removable VESA plate guarantees a quick and easy installation.
- Optimum viewing angle and maximum flexibility through full mobility in tilt (up/down from +5° to -8°) and swivel (left/right by ±60°)
- The wallmount keeps the TV in the position with only 50mm elegantly flat and space-saving on the wall and can be extended up to 510mm to achieve the optimal viewing angle.
- L'articulation réglable du bras en ciseaux soutient l'extension et stabilise le mouvement.
- The removable VESA plate allows quick and easy installation.
- suitable wall bracket for most flat and curved TVs of all popular brands (e.g. Samsung, Sony, Philips, LG) and sizes (e.g. 40", 43", 49", 50", 55", 58", 65")
- Easy mounting and compatible with VESA standards 200x100, 200x200, 300x200, 300x300, 400x200, 400x300, 400x400, 600x400.
Technical specifications
General
Packaging type
Retail Box
Consumption Unit
1 pc. cardboard box
Color
black
Material
steel (powder-coated)
Width
432.5 mm
Height
510 mm
depth
371 mm
Performance
screen Size
94 - 178 inch
maximum load
30 kg
wall distance
50 - 510
turn / swivel range
60 °
inclination and tilting ranges
8 °
VESA (FDMI)
100 x 100 mm, 200 x 100 mm, 200 x 200 mm, 300 x 200 mm, 400 x 200 mm
Scope of delivery
Assembly Material
dowel, screws
Language Scope
Operation manual
se, en, de, cz, fr, da, pl, it, es, nl
Downloads
Packing units:
1 / 3
Item: 49956
EAN: 4040849499562
