Casual
USB 3.0 Extension
high speed extension for a type-A USB plug
Casual
USB 3.0 Extension
high speed extension for a type-A USB plug
Article details
If you’ve ever thought your USB cable is too short, this practical extension is for you. Its multiple signal shielding, pure materials and precise workmanship enable this coupling to extend the reach of type-A plugs by another much-needed metre.
- extension cord compatible with USB 3.0/2.0 type-A plugs
- SuperSpeed data transmission at up to 5 Gbit/s – 10 times faster than USB 2.0
- disturbance-free signal flow through pure copper conductor and double shielding
- 24 carat gold-plated contacts for minimum transmission resistance
- Long-term usable due to flexible and robust PVC jacket, which can be bent optimally and simplifies the laying of the cable
- Even after many years, crystal-clear picture and sound quality and rust-free connections thanks to 24-carat gold-plated connectors
Technical specifications
General
Packaging type
Retail Box
Consumption Unit
1 pc. in cardboard box
Markings
WEEE, CE
Operating temperature from
-10 °C
Operating temperature up to
80 °C
Warranty
10 years
Connections
Connection, shielding
yes
Connection, length
48 mm
Connection, width
15 mm
Connection, type
USB 3.0 male (type A)
Connection, height
7.5 mm
Connection 2, type
USB 3.0 female (Type A)
Connection 2, length
41.3 mm
Connection 2, width
16.5 mm
Connection 2, height
9.3 mm
Connection, contact material
gold (24 kt)
Cable
Cable type
round cable
Cable length
1.8 m
Inner conductor material
OFC (99,9% oxygen-free copper)
AWG
29
Type 2, shielding
braid (copper) 112x
Cable sheath diameter (approx.)
5 mm
Inner Conductor number
7 pieces
inner conductor, core diameter
0.12
Kink protection
both sides
Signal transmission
max. transmission rate
5 Gbit/s
Downloads
Packing units:
1 / 20 / 40
Item: 70119
EAN: 4040849701191
